Product Advisory Notice

28 July 2018
FITTING OF AXLE – FRONT WHEEL POTENTIAL BREAKAGE

The Problem:
Several customers have experienced breakage of the front wheel mounting, when operating as 3 wheel, manual trolley.

Advice:
1. Refer to Owners Manual for correct axle positioning. Note marks on axle mount
2. \ / orientation is ONLY for use in STAND mode.
3. / \ is correct orientation for 2and 3 wheel operation ( brake lever will be on the right ).
4. Axle must be released to the extended position. NOT fully inserted.
5. If a customer suffers a front wheel breakage please take note of the axle position, and advise us immediately for a replacement wheel.

The Cause:
We believe this problem may be a result of operation with incorrect axle position when in 3 wheel manual mode. This changes the trolley geometry and, under some conditions on rough or uneven surfaces, results in stress on the front wheel mount beyond design limits.
